HALSHIKKUI® Technology

HALSHIKKUI

Concept

Plaster Can be Easily Available for Anyone & Anywhere.

HALSHIKKUI is PSA-film sheet, the surface of which is coated with plaster, developed with the concept that the plaster material is not painted but attached to adherent, that offers you a comfort of its application options.
HALSHIKKUI has not only the functions of the plaster with such as Anti-fungus, Deodorization, Anti-bacteria, Anti-virus and Humidity control, but also the performances of the adhesive sheet named MATRIX® removable and reposition-able.

Cost Performance and High Functionalities

You do NOT require advanced craftsman's techniques or complex processes, and it is excellent in cost performance,
that has high functionality (deodorant, antibacterial, antivirus, dew condensation suppression, VOCs adsorption) of plaster by simply sticking of PSA-film series: HALSIKKUI.

"Stick", "Cut", "Pull out", "Printed" on Your Easy Ways

Various Process methods are possible by using an PSA-film sheet.
Various developments are possible as Stickers / Labels, from high-performance wallpaper, wall sticker applications to antibacterial stickers or deodorant labels.

"Stick", "Cut", "Pull out", "Printed" on Your Easy Ways"Stick", "Cut", "Pull out", "Printed" on Your Easy Ways"Stick", "Cut", "Pull out", "Printed" on Your Easy Ways"Stick", "Cut", "Pull out", "Printed" on Your Easy Ways

What is Plaster Coating?

Main Ingredient:
Slaked Lime CaCa(OH)2
  • Product of Nature Made of Coral Fossils
  • It has been used as a traditional Japanese material on the inner and outer walls of castles and warehouses since ancient times.
  • In addition to the unique texture and texture of natural materials, it has functions that contribute to people's health and the environment.
What is Plaster Coating?

Plaster Can be Seen Even in such Occasions!

Plaster Can be Seen Even in such Occasions!
Plaster Can be Seen Even in such Occasions!

Properties of Plaster Coating

1. Strong Alkaline

Repels Bacteria, Mold and Viruses due to Strong Alkaline Value of over Acid Index: pH-11

2. Porous structure

Trapped Chemicals in Countless Holes (Physical Adsorption)

Trapped Chemicals in Countless Holes (Physical Adsorption)
Trapped Chemicals in Countless Holes (Physical Adsorption)

Electron microscope (SEM) Magnification: 3000x

  • Adsorbs & Removes Chemicals by the Surface of Pores
  • Inactivation by Chemical Reaction resulting from its Strong Alkalinity

Expression of Functional Effects

  • Deodorant Effect
  • Antibacterial and antiviral properties
  • Dew Condensation Control
  • Allergen Reduction
  • VOC Adsorption
  • CO2Adsorption

About HALSHIKKUI

Product Composition

Product Composition of HALSHIKKUI

※Please scroll

Product Name Substrate Adhesive type
R-HALSHIKKUI V NW(shironori)-MX3 Non-woven fabric (50g/m2) Removable (white)
R-HALSHIKKUI V PET-MX3 White PET film Removable (transparent)
NA-HALSHIKKUI 50-NW Non-woven fabric(50g/m2 (No adhesion)

*Made to Order

  • "ALES SHIKKUI" is a registered trademark by Kansai Paint Co., Ltd.

Characteristic

※Please scroll

Adhesive Force (Peel Strength)
[N/25mm]
Product Name Measurement method
R-HALSHIKKUI V
NW White Glue-MX3
R-HALSHIKKUI V
PET-MX3
Stainless Data after 20-minutes 7.1 6.8 ・JIS Z0237(2000)
・2kg rubber roller 1 round crimping
・180°peeling
・300mm/min Peeling speed 300mm / min
・easured environment 23 ℃ ・ 50% RH
・Stainless steel # 360 polishing
Data after 24-hour 8.2 7.3
Glass Data after 20-minutes 6.3 5.1
Data after 24-hour 6.5 5.4
PVC Data after 20-minutes 6.3 5.5
Data after 24-hour 6.5 6.5
  • MATRIX Process: PSA Coating Process with Good Air Release-ability
  • Colored PSA: Uses White Glue with Improved Concealment
  • Standard: 960mm×20m、480mm×50m
Characteristic

Effects of HALSHIKKUI's Function

1.Deodorant Effect

Hydrogen Sulfide: smell of tobacco and garbage

Hydrogen Sulfide: smell of tobacco and garbage

Mercaptan Compounds ... smell of garbage

Mercaptan Compounds ... smell of garbage

*HALSHIKKUI (150 mm x 150 mm) set in a 5L Tedlar bag, then a certain concentration of hydrogen sulfide or methyl-mercaptan filled & injected to measure the concentration of the relevant chemicals in this volume.

tobacco

garbage

toilet

pet

2.Dew Condensation Control

Capture Moisture Vapor in the Air in the Micro Pores!
Capture Moisture Vapor in the Air in the Micro Pore
Capture Moisture Vapor in the Air in the Micro Pore

*Put the test piece in a glass bottle, drop the water, cover and leave it at 23 ° C for 24 hours
After that, it was allowed to stand at 10 ° C for 30 minutes, and then the condensation inside of the bottle checked.

Put the test piece in a glass bottle, drop the water, cover and leave it at 23 ° C for 24 hours After that, it was allowed to stand at 10 ° C for 30 minutes, and then the condensation inside of the bottle checked.

3.VOC Adsorption

Counter-check for Sick-house Syndrome

When you move into a newly built or renovated house, you may have symptoms called "sick-house syndrome", such as flickering eyes, sore throat, dizziness, nausea, and headache.

One of the cause is thought to be volatile organic compounds(VOCs) such as formaldehyde, toluene emitted from building materials, furniture, and daily necessities.

Formaldehyde

HCHO → saccharide ※Ca(OH)2a catalyst/div> Formaldehyde

Toluene

Adsorbed to Numerous Micro Pores in the Coated Plaster
Toluene

*HALSHIKKUI (150 mm x 150 mm) moistened with pure water set in a 5L Tedlar bag, then a certain concentration of HCHO/ Toluene filled & injected to measure the concentration of the relevant chemicals in this volume.

HALSHIKKUI has been confirmed to adsorb and decompose those chemicals by the micro porous structure of its own.

4.Antibacterial and Antiviral Properties

Avian influenza H5N1 virus

Antibacterial and Antiviral Properties

Slaked lime as the main component is strongly alkaline (pH 11 or more) and has high antiviral properties. Nano-sized virus is adsorbed on the micro pores of slaked lime and detoxified.

  • Survey at the Institute for Microbial Diseases in Osaka University
  • With an Effect on Virus Growth Suppression, but does not Guarantee Infection Prevention.
  • It does not Contain Organic Chemicals such as Antibacterial Agents and Fungicides.

5.Allergen Reduction

Mite Allergen

Mite Allergen

Cedar Pollen

Cedar Pollen

*Place 0.03 g of HALSHIKKUI in a vial, and drop 0.5 ml of the allergen suspension. After 1 hour, extract and measure the amount of allergen.

It is considered that slaked lime is taken into the porous structure and deteriorates under the influence of strong alkali, resulting in lower allergens.

6.CO2Absorbing Effect

Ca(OH)2 + CO2 → CaCO3 + H2O
CO2bsorbing Effect
CO2bsorbing Effect

*HALSHIKKUI (150 mm x 150 mm) moistened with pure water set in a 5L Tedlar bag, then a certain concentration of CO2 filled & injected to measure the concentration of the relevant chemicals in this volume.

Advantages of HALSHIKKUI

HALSHIKKUI for the Space you can't Put on

Conservative plaster on a wall for example, where a craftsman coating it on may be limited & complex as well,
because it takes a lot of hours to paste it for work at many procedures with its curing stage inclusive.
In addition, if a stress strain on the plaster such as a curved surface is applied, it may be fragile down as itself.

"HALSSIKUI" composed from plaster & PSA-film sheet, does not generate dust even if it gets bent or die-cut with a NEION's technology. Also it is possible to print on it, product development with design and functionality. Anyone can easily stick it anywhere by our PSA-film series: MATRIX version.

Secondary Process

Die cutting

Die cutting

Printing

Printing

Embossing

Embossing

Wide Operation Area → Proposal other than Wall

Glass/ Resin Plate

Glass/ Resin Plate

Inside the Car

Inside the Car

Furniture

Furniture
